Product Description

The JL682A is the HPE Aruba 5406R zl2 Switch, a modular managed switch designed to provide high-performance and scalable networking solutions for enterprise data centers and large networks. Featuring a flexible modular design, the JL682A supports various types of modules, including Gigabit Ethernet and 10-Gigabit SFP+ ports. With its robust Layer 3 capabilities, advanced security features, and high throughput, this switch is ideal for handling demanding applications and ensuring reliable, high-speed network connectivity.

Technical Specifications

• Product Number: JL682A
• Type: Modular Managed Ethernet Switch
• Ports:
• Base Configuration: 24 x 10/100/1000 Mbps Gigabit Ethernet ports
• Expansion Slots: 4 x Modular (for additional modules, such as 10G SFP+ or 1G SFP)
• Switching Capacity: Up to 440 Gbps
• Forwarding Rate: Up to 326 Mpps (Million Packets Per Second)
• Layer: Layer 3
• Management: Aruba Central, Web-based GUI, SNMP, CLI
• PoE+ Support: Optional via modules
• VLAN Support: Yes, with 802.1Q VLAN tagging
• QoS (Quality of Service): Yes
• Dimensions (H x W x D): 44.5 x 440 x 365 mm (1.75 x 17.32 x 14.37 in)
• Weight: Approximately 8.2 kg (18.1 lbs)
• Rack Mountable: Yes (rack ears included)
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az
