Product Description

R7MZ20030BS1 SMARTSTEP JR MTR 200W W/BRK The R7M-Z20030-BS1 is a robust and high-performance servo motor from Omron’s R7M series, designed to deliver precise and efficient motion control for a wide range of industrial automation applications. This model features a 200W power rating and integrates advanced control technologies to provide smooth and accurate motion. The R7M-Z20030-BS1 is ideal for applications requiring high torque and speed precision, making it suitable for tasks such as positioning, speed control, and torque control in various machinery and automated systems.

Technical Specifications

• Model: R7M-Z20030-BS1
• Type: Servo Motor
• Power Rating: 200W
• Rated Voltage: 100-240V AC
• Rated Current: 1.6A
• Rated Speed: 3000 RPM
• Torque:
• Rated Torque: 0.64 Nm
• Peak Torque: 1.92 Nm
• Feedback Device: Incremental encoder with 2500 pulses per revolution
• Brake: Optional (model variant)
• Operating Temperature Range: 0°C to +40°C
• Storage Temperature Range: -20°C to +60°C
• Dimensions (W x H x D): 60 x 60 x 130 mm
• Weight: Approximately 2.5 kg
• Mounting Type: Flange mountable
• Environmental Protection: IP54 (dust-tight, protected against water splashes from any direction)
• Compliance: RoHS compliant
