Mitsubishi QY81P PLC Module QY81P

Description:

QY81P OUTPUT MODULE PLC Q SERIES 32 TRANSISTOR OUTPUTS 12-24 VDC 0.1 AMP SOURCE OUTPUT LOGIC SUB-D CONNECTOR The Mitsubishi QY81P is a high-performance relay output module for the Q-Series programmable logic controllers (PLCs). This module features 8 relay outputs, designed to manage and control a variety of electrical loads with reliable switching capabilities. It is well-suited for applications requiring precise control of multiple devices and machinery, offering durability and ease of integration with the Q-Series PLC systems. The QY81P module is an ideal choice for applications where high reliability and flexibility in output control are essential.

Technical Specifications:

• Type: Relay output module
• Output Points: 8 relay outputs
• Output Voltage: 24V DC, 120V AC, or 230V AC (depending on relay type)
• Output Current: 2A per relay (max)
• Contact Type: SPDT (Single Pole Double Throw)
• Response Time: Typically 5 ms (on/off)
• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Dimensions: 90 x 90 x 75 mm (3.54 x 3.54 x 2.95 inches)
• Weight: Approximately 0.5 kg (1.1 lbs)
• Isolation: 3,000V AC isolation between output and PLC
• Mounting: Connects directly to the Q-Series PLC backplane
• Features: High reliability, flexible output control, and seamless integration with Q-Series PLCs
