Siemens 6AV6643-0CB01-1AX1 HMI Panel 6AV66430CB011AX1

Description:

The Siemens 6AV6643-0CB01-1AX1 HMI panel is used in SIMATIC MP277 industrial automation systems for operator interface control. Commonly installed in production lines, packaging machines, and process control systems. Maintenance teams, OEMs, and system integrators use this part for replacement, retrofit, and real-time monitoring and control of industrial processes.

Applications:

The Siemens 6AV6643-0CB01-1AX1 is used to visualize and control machine operations in industrial environments. It is widely applied in manufacturing systems, material handling, and process automation where operators require real-time data display, touchscreen interaction, and system diagnostics for efficient and safe operation. This MP277 panel supports integration with PLC systems via industrial communication interfaces.

Technical Specifications:

• Manufacturer Part Number (MPN): 6AV6643-0CB01-1AX1
• Product Type: HMI Panel / Operator Interface
• Series: SIMATIC MP277
• Display Size: 7.5-inch TFT touchscreen
• Resolution: 640 × 480 pixels
• Memory: 6 MB configuration memory
• Communication Interfaces: RS422, RS485, Ethernet (RJ45)
• Configuration Software: WinCC Flexible 2005
• Input Method: Touchscreen
• Mounting Type: Panel mount
• Weight: Approx. 1.6–2.3 kg
• Product Status: Discontinued

Common Replacements:

• Siemens 6AV6643-0CB01-1AX2
• Siemens 6AV6643-0DB01-1AX1
• Siemens 6AV2123-2GB03-0AX0
