ABB PSR30-600-70 PSR3060070 Soft Starter

DESCRIPTION
The ABB PSR30-600-70 is a compact soft starter designed for controlling 3-phase motors up to 30 amps. Operating at voltages up to 600V AC, this soft starter features a 24V AC/DC control voltage and offers a simple, cost-effective solution for reducing inrush current and mechanical stress during motor startup. The PSR series is ideal for applications requiring space efficiency and reliable motor control without advanced functionality.

TECHNICAL SPECIFICATIONS
Model: PSR30-600-70
Rated Operational Voltage: 208–600V AC
Rated Operational Current (Ie): 30 A
Control Supply Voltage: 24V AC/DC
Phases: 3
Rated Frequency: 50/60 Hz
Motor Power Range: Approx. 15 HP at 460V
Start/Stop Ramps: Adjustable
Bypass: Built-in
Mounting: DIN rail or screw mounting
Width: 45 mm
Standards: IEC/EN 60947-4-2, UL, CSA
