Action Instruments V560EP Loop Powered LCD Indicator

Action Instruments V560 EP Loop Powered LCD Indicator is a rugged intrinsically safe loop-powered display designed for hazardous locations, deriving power directly from a 4–20 mA current loop and presenting readings on a 0.8" LCD, 3½ digits (1999 counts). The EP (explosion‑proof) housing variant carries FM and CSA intrinsic safety approvals (FM17US0096; LR422272‑45) for Class I/II environments and operates from -10°C to 70°C (with storage −55°C to 85°C). It supports 4–20 mA and 10–50 mA input ranges (switch-selectable) with a 3–100 mA input current limit and a 3.9 V maximum input drop at full scale, while drawing up to 12 mW of power at 3 mA input. Readouts update at 2.5 conversions per second and the display includes four-position decimal point control (1.9.9.9) with a trailing-zero option for values like 19990; the calibration allows Zero from −1999 to 1999 and Span from 100 to 3998 counts. The V560 EP weighs about 11 lb and uses front-panel 10-32 brass screws with corrosion‑resistant stainless plating and rear 6-32 nickel‑plated brass screws. For ordering, specify model V560 or V860 with options C (conduit housing), EP (explosion‑proof housing), or U (urethane coating), and choose mounting variants as needed (including T901/T906 kits for EP).
