Airtrol's F-4200-30-FM-B85 is a compact SPDT pressure-to-electric switch in the F-4200 series, designed for OEM applications where space and cost are critical. It is adjustable from 0.5 to 30 psi (full scale) with a max overpressure of 60 psi, and a deadband of 1.8 psi typical (2.4 psi max), delivering a 10 A current rating through.187" quick-connect terminals and a 1/8" barb fitting for the flush-mount (FM) configuration. The wetted body is polysulfone with a polyurethane diaphragm and a stainless steel spring, and it operates from 40°F to 150°F, with UL/CSA approval; four mounting styles are available in the F-4200 family to fit different installations.
