Allen-Bradley 100-C09EJ10 IEC Contactor – 9A, 24V DC Coil, 3-Pole, 1 N.O. Auxiliary 100C09EJ10

Description:

The Allen-Bradley 100-C09EJ10 IEC Contactor is used in industrial motor control and power switching systems to reliably switch three-phase AC loads and control motor starters with a DC coil interface. Commonly installed in control panels, motor control centers, HVAC systems, pumps, and manufacturing equipment where dependable contact switching and overload handling are required. Maintenance teams and system integrators use this contactor for motor starter replacements, control panel retrofits, system expansions, and restoration of failed switching components.

Applications:

The Allen-Bradley 100-C09EJ10 contactor is commonly used in industrial automation environments including material handling systems, water and wastewater facilities, processing plants, commercial building automation, and general power distribution panels where precise contact switching with DC coil control improves operational reliability and control flexibility.

Technical Specifications:

• Manufacturer: Allen-Bradley
• Model: 100-C09EJ10
• Product Type: IEC Industrial Contactor
• Rated Operational Current (AC-3): 9 A
• Coil Voltage: 24 V DC
• Poles: 3 main poles with 1 N.O. auxiliary contact
• Rated Operational Voltage: Up to typical industrial AC loads (verify application)
• Frequency: 50/60 Hz operation
• Mounting Type: Panel or DIN rail mounted contactor
• Contact Material: Industrial grade silver alloy contacts
• Application Category: Motor control and power switching
• Operating Temperature Range: Industrial-rated conditions

Common Replacements:

• Allen-Bradley 100-C09EJ00 Contactor
• Allen-Bradley 100-C09D10 Contactor
• ABB AF09-30-11 Contactor
