Allen-Bradley 100-C72DJ10 Contactor, 24VDC Coil w/ Diode 100C72DJ10

Description:

The Allen-Bradley 100-C72DJ10 Contactor is an industrial motor control contactor designed for switching electrical loads in automation and motor control systems. Equipped with a 24V DC coil and integrated suppression diode, this contactor provides reliable switching performance and protection against voltage spikes in control circuits. Maintenance teams, OEM machine builders, and system integrators use this contactor for motor control panel assemblies, equipment upgrades, system retrofits, and replacement of worn or failed contactors in industrial power distribution systems.

Applications:

The 100-C72DJ10 contactor is widely used in industrial automation and motor control applications where dependable load switching is required. Typical installations include motor starters, pump and fan control circuits, conveyor systems, HVAC equipment, and machinery control panels that require reliable switching of three-phase motors and electrical loads. Its compact design and DC coil configuration make it suitable for modern PLC-controlled automation systems.

Technical Specifications:

• Manufacturer: Allen-Bradley
• Part Number: 100-C72DJ10
• Series: Bulletin 100-C Contactors
• Contactor Type: 3-pole power contactor
• Coil Voltage: 24V DC
• Coil Protection: Integrated suppression diode
• Rated Operational Current: 72 A
• Rated Operational Voltage: Up to 690V AC
• Mounting Type: DIN rail or panel mount
• Auxiliary Contacts: Configurable with add-on auxiliary blocks
• Operating Temperature: 0°C to 60°C

Common Replacements:

• Allen-Bradley 100-C60DJ10
• Allen-Bradley 100-C85DJ10
• Siemens 3RT2036-1BB40
