Allen-Bradley 1769-IF4XOF2 CompactLogix Analog 4 inputs 2 outputs 1769IF4XOF2
Allen-Bradley 1769-IF4XOF2 CompactLogix Analog 4 inputs 2 outputs 1769IF4XOF2
Couldn't load pickup availability





Description:
The Allen-Bradley 1769-IF4XOF2 is a Compact I/O analog combination module featuring four analog input channels and two analog output channels. Designed for use with CompactLogix and MicroLogix 1500 controllers, this versatile module allows both monitoring and control of analog signals within a single slot. It supports multiple voltage and current ranges and provides high-resolution data acquisition and output capabilities. Ideal for compact and mid-sized control systems, the module offers seamless integration into Rockwell Automation platforms using Studio 5000 or RSLogix 5000.
TECHNICAL SPECIFICATIONS:
Model: 1769-IF4XOF2
Series: Compact I/O
Analog Inputs: 4 channels (single-ended or differential)
Analog Input Ranges:
Voltage: ±10V, 0–10V, 0–5V, 1–5V
Current: 0–20 mA, 4–20 mA
Analog Outputs: 2 channels
Analog Output Ranges:
Voltage: 0–10V, ±10V
Current: 0–20 mA, 4–20 mA
Resolution:
Inputs: 15 bits
Outputs: 14 bits
Accuracy: ±0.5% full scale at 25°C
Conversion Rate: ~250 ms for all channels
Backplane Current Draw: 120 mA @ 5V DC, 85 mA @ 24V DC
Isolation Voltage: 30V (continuous), basic insulation
Mounting: DIN rail or panel mount
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Dimensions: 118 mm x 87 mm x 35 mm (H x D x W)
Weight: Approx. 0.3 kg (0.66 lbs)
