Allen-Bradley 1769-IF8 8 Pt Analog Input Module 1769IF8

Description:

The Allen-Bradley 1769-IF8 8 Pt Analog Input Module is used in industrial automation systems to provide multiple analog input channels for accurate measurement of process signals such as voltage and current. Commonly installed in CompactLogix PLC racks, control panels, and distributed I/O systems where dependable analog input acquisition is required for real-time monitoring and feedback control. Maintenance teams and system integrators use this module for I/O expansions, retrofit upgrades, replacement of failed analog input modules, and enhanced analog signal measurement.

Applications:

The Allen-Bradley 1769-IF8 analog input module is commonly used in industrial environments including manufacturing production lines, water and wastewater treatment facilities, HVAC and building automation systems, chemical processing equipment, material handling systems, and packaging machinery where accurate multi-channel analog input improves process control, diagnostics, and overall system performance.

Technical Specifications:

• Manufacturer: Allen-Bradley
• Model: 1769-IF8
• Product Type: CompactLogix 8 Pt Analog Input Module
• Input Channels: 8 independent analog inputs
• Input Signal Types: Voltage and current (model dependent)
• Resolution: High-resolution analog-to-digital conversion
• Compatibility: Rockwell Automation CompactLogix I/O systems
• Interface: 1769 Compact I/O backplane connection
• Mounting Type: DIN rail or panel mount module
• Power Supply: Supplied via CompactLogix power rail
• Function: Acquires analog signals for PLC logic and process monitoring
• Application Category: Industrial analog data acquisition and control
• Operating Temperature Range: Industrial-rated conditions
• Protection Rating: Installed within control enclosure

Common Replacements:

• Allen-Bradley 1769-IF4 CompactLogix 4 Pt Analog Input Module
• Allen-Bradley 1756-IF8 ControlLogix 8 Pt Analog Input Module
• Allen-Bradley 1734-IE8S POINT I/O 8 Pt Analog Input Module
