Allen-Bradley 1769-IQ16 CompactLogix 16 Pt 24VDC Input Module 1769IQ16

Description:

The Allen-Bradley 1769-IQ16 CompactLogix 16 Point 24VDC Input Module is used in CompactLogix and MicroLogix 1500 control systems to provide sixteen discrete 24V DC digital input channels for industrial automation applications. Commonly installed in machine control panels for packaging lines, conveyor systems, motor control centers, and process equipment, it enables reliable monitoring of field devices such as sensors and switches. Maintenance teams and system integrators use this module for input expansion, system upgrades, panel retrofits, and replacement of failed digital input modules in Compact I/O platforms.

Applications:

The 1769-IQ16 module is applied in manufacturing systems, material handling equipment, food and beverage processing lines, water and wastewater facilities, and OEM machinery where dependable 24V DC discrete input monitoring is required for proximity sensors, limit switches, push buttons, and other field devices.

Technical Specifications:

• Manufacturer Part Number (MPN): 1769-IQ16
• Product Type: Digital DC Input Module
• Series: Compact I/O (1769)
• Number of Inputs: 16
• Input Voltage: 24V DC
• Input Voltage Range: 10–30V DC
• Input Type: Sinking/Sourcing compatible
• Input Current: 6 mA nominal at 24V DC
• Backplane Current Draw: 120 mA at 5V DC
• Isolation: Group isolated inputs
• Mounting: DIN Rail or Panel Mount (Compact I/O system)
• Compatible Controllers: CompactLogix and MicroLogix 1500
• Operating Temperature: 0°C to 60°C

Common Replacements:

• Allen-Bradley 1769-IQ16F
• Allen-Bradley 1769-IA16
• Allen-Bradley 1734-IB8
