Allen-Bradley 1769-OW16 CompactLogix Relay 1769OW16

Description:

The Allen-Bradley 1769-OW16 CompactLogix Relay Module is used in industrial automation systems to provide relay-based digital output switching for control and signaling functions. Commonly installed in CompactLogix PLC racks, control cabinets, and distributed I/O systems where reliable relay actuation and isolation of external loads are required. Maintenance teams and system integrators use this relay module for control system expansions, retrofit upgrades, replacement of failed output modules, and enhancement of automation panel functionality.

Applications:

The Allen-Bradley 1769-OW16 relay module is commonly used in industrial automation environments including manufacturing production lines, packaging systems, material handling conveyors, water and wastewater facilities, HVAC control systems, and general machine control panels where dependable relay outputs interface with solenoids, lights, valves, and other field devices.

Technical Specifications:

• Manufacturer: Allen-Bradley
• Model: 1769-OW16
• Product Type: CompactLogix Relay Output Module
• Output Channels: 16 relay outputs (form A / SPST)
• Output Type: Relay contact switching for digital loads
• Load Voltage: AC/DC load switching capability (model dependent)
• Isolation: Optically isolated outputs (model dependent)
• Compatibility: CompactLogix PLC and Compact I/O backplane
• Installation: Rack or DIN rail mounted module
• Power Supply: Supplied from CompactLogix rack power
• Function: Controls field devices via relay contacts
• Application Category: Digital output switching and control
• Operating Temperature Range: Industrial-rated conditions

Common Replacements:

• Allen-Bradley 1769-OW8 Relay Output Module
• Allen-Bradley 1734-OW16 POINT I/O Relay Module
• Allen-Bradley 1756-OW16 ControlLogix Relay Output Module
