Allen-Bradley 22F-D8P7N103 3.7 kW 5 HP AC 22FD8P7N103

Description:

The Allen-Bradley 22F-D8P7N103 PowerFlex 70 AC Drive is a variable frequency drive used in industrial motor control systems requiring adjustable speed and torque performance. Designed for 380–480V three-phase input, this 3.7 kW (5 HP) drive delivers dependable operation for pumps, fans, conveyors, and general-purpose machinery in manufacturing environments. Maintenance teams, OEM machine builders, and system integrators use this drive for equipment repair, panel retrofits, system upgrades, and direct replacement of aging or failed VFD units in automated control systems.

Applications:

The Allen-Bradley PowerFlex 70 AC drive is widely applied in industrial automation to control three-phase induction motors in diverse equipment. Typical installations include material handling systems, packaging lines, HVAC units, compressors, and water/wastewater processing stations where consistent speed regulation and energy efficiency are required. Its robust design supports standalone machines as well as integration into distributed control architectures.

Technical Specifications:

• Manufacturer: Allen-Bradley
• Part Number: 22F-D8P7N103
• Series: PowerFlex 70
• Rated Output Current: 8.7 A
• Input Voltage: 380–480V AC, 3-phase
• Output Voltage: 0–460V AC
• Power Rating: 3.7 kW (5 HP)
• Control Method: V/Hz Control, Sensorless Vector
• Enclosure Rating: IP20 (Open Type)
• Mounting Type: Panel mount
• Output Frequency Range: 0–500 Hz
• Ambient Operating Temperature: 0°C to 50°C (without derating)

Common Replacements:

• Allen-Bradley 22F-D010N104
• Allen-Bradley 25B-D8P7N104
• Siemens 6SL3210-1PE21-5UL0
