Description:
The Allen-Bradley 5069-ARM is a Compact 5000 Address Reserve Module used in 5069 Compact I/O systems to reserve communication addresses within Logix 5000 control architectures. It allows system designers to allocate and maintain I/O slot addressing for future expansion or planned module additions without requiring controller reconfiguration. Commonly installed in machine control panels, modular production systems, and scalable automation platforms, this module supports structured system growth and organized rack layouts. Maintenance teams and system integrators use this module during initial panel builds, phased installations, retrofit projects, and system expansions to maintain consistent addressing and reduce future downtime.
Applications:
The 5069-ARM address reserve module is used in Compact 5000 I/O assemblies where planned expansion or staged commissioning requires pre-defined I/O addressing. It is widely applied in automated manufacturing lines, packaging systems, material handling equipment, and OEM machinery where maintaining network structure and minimizing controller reconfiguration are critical for scalable automation design.
Technical Specifications:
• Manufacturer Part Number (MPN): 5069-ARM
• Brand: Allen-Bradley
• Product Type: Address Reserve Module
• I/O Platform: 5069 Compact I/O (Compact 5000)
• Function: Reserves communication address/slot position
• Communication Interface: Integrated backplane
• Power Consumption: Minimal backplane load
• Mounting: DIN rail
• Installation Location: 5069 I/O assembly
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Compatibility: Logix 5000 controllers
Common Replacements:
• Allen-Bradley 5069-IB16
• Allen-Bradley 5069-OB16
• Allen-Bradley 5069-AEN2TR
