Allen-Bradley 800FP-KR31R Selector Switch Knob Assembly

The Allen-Bradley 800FP-KR31R is a 22.5 mm mounting-hole, non-illuminated three-position selector switch with spring return from the right and left-key removal capability, designated with key code 455. It ships as a standard pack (1 unit) without a power module or lamp, and includes a plastic front ring; the latch material is plastic and the front ring is included. The unit provides a 10 A thermal current rating on its contact block and is rated for IP66, Type 4/13 enclosure compatibility for round plastic operators, with an operator function of spring return from the right and three positions. Operating conditions specify a -25 °C operating temperature, up to 95% RH from 25–60 °C, and storage down to -40 °C; mechanical life is up to 1,000,000 cycles, and the product is manufactured in China with UPC 662468101523.
