Allen-Bradley 800H-PK46R is a 480 VAC pilot light accessory for the 800H family of 30 mm pushbutton stations. It mounts in a 30.5 mm mounting hole and uses screw-terminal connections for 14–18 AWG conductors, with termination torque of 6–8 in-lb. It supports enclosure compatibility with NEMA 1, 4, 4X, 12, and 13, and is designed to withstand rugged environments with up to 100 G shock and 10 G vibration, operating at -25°C and storing at -40°C with humidity up to 50%. Within the 800H line, similar pilot-light variants include incandescent 800H-PR46R and LED 800H-PRH46R, both rated for 480 VAC input.
