Allen-Bradley 800MR-PDT16R NSMP is a 22.5 mm round pilot light module with a red lens and a built‑in dual‑input transformer designed for 110–120 V AC operation in control panels. The NSMP variant combines an incandescent pilot lamp with a dual input transformer and stab-terminal wiring for quick, secure connections, and is specified as a dual input pilot light in standard configurations. This unit is intended to provide bright, easily visible signaling in industrial automation—ideal for indicating run, stop, fault, or other status conditions within machine controls, conveyors, pumps, presses, and packaging lines—within a compact 22.5 mm footprint that fits standard panel openings.
