Allen-Bradley 800T-QH10A Pilot Light Indicator

Description:

The Allen-Bradley 800T-QH10A Pilot Light is a 30.5 mm illuminated pilot light with an amber extended (high-head) lens and a 120 VAC/DC full-voltage incandescent illumination module. It is designed to provide highly visible machine and process status indication in heavy-duty industrial control systems. Commonly installed in motor control centers, industrial control panels, operator stations, and manufacturing equipment where reliable visual indication is required. Maintenance teams and system integrators use this pilot light for OEM replacement, control panel assembly, retrofit projects, and industrial automation maintenance.

Applications:

The Allen-Bradley 800T-QH10A is used for indicating machine operating status, power availability, process conditions, and alarm signals in packaging machinery, conveyor systems, material handling equipment, water and wastewater facilities, process automation systems, and manufacturing production lines. Its extended amber lens provides improved visibility in applications where operator status indication must be easily recognized from a distance.

Technical Specifications:

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Part Number: 800T-QH10A
• Product Type: Pilot Light
• Series: Bulletin 800T
• Operator Size: 30.5 mm NEMA
• Operator Type: Extended Head Pilot Light
• Lens Color: Amber
• Lens Style: High Head (Extended) Fresnel Lens
• Illumination Type: Full-Voltage Incandescent
• Illumination Module Input Voltage: 120 VAC/DC
• Number of Indicator Lights: 1
• Mounting Hole Diameter: 30.5 mm
• Operator Construction: Metal Body with Plastic Lens
• Electrical Connection: Screw Terminals
• Enclosure Rating: NEMA Type 1, 4, 12, and 13
• Vibration Rating: 10 G Maximum
• Shock Rating: 100 G (No Damage)
• Operating Temperature: -25°C Minimum
• Storage Temperature: -40°C Minimum
• Certifications: UL Listed, CSA Certified, CE, CCC, EAC
• Features: High-visibility amber extended lens, heavy-duty industrial construction, oil-tight sealing, modular design, and long service life.

Common Replacements:

• Allen-Bradley 800TC-QH10A
• Allen-Bradley 800T-Q10A
• Allen-Bradley 800T-QT10A
