Allen-Bradley CP02R-04-3045 Operator Interface

Description:

The UNIOP CP02R-04-3045 Operator Interface is used in human-machine interface (HMI) systems to provide operators with machine monitoring and process control capabilities. Commonly installed in PLC-controlled manufacturing equipment, packaging machinery, material handling systems, and industrial automation processes requiring operator interaction and status visualization. Maintenance teams and system integrators use this part for replacement, retrofit, and expansion of existing HMI installations.

Applications:

The UNIOP CP02R-04-3045 Operator Interface is used in industrial environments requiring communication between operators and automated equipment. It is commonly applied in production lines, assembly machinery, packaging systems, and process control applications where operators need to monitor machine conditions, input commands, and adjust operating parameters to support efficient equipment operation and minimize downtime.

Technical Specifications:

• Brand: UNIOP
• Part Number: CP02R-04-3045
• Product Type: Operator Interface
• Display Type: 4 x 20 LCD display
• Function Keys: 16 user-programmable keys
• System Keys: 18 keys
• User LEDs: 16
• System LEDs: 1
• Power Supply: 24 VDC
• Communication Ports: PLC port, PC/Printer port, and AUX port
• Programming Software: UniOP Designer 6
• Recipe Memory: 16 KB
• Alarm Capacity: 1024 alarms
• Event List Capacity: 256 events
• Installation Type: Panel-mounted configuration
• System Type: Human-machine interface (HMI) system
• Intended Use: Replacement and maintenance service

Common Replacements:

• UNIOP CP02R-04-3045 Operator Interface
• UNIOP CP02R-04 Operator Interface
• EXOR UniOP Operator Interface
