Allen-Bradley Micro800 2 Point Analog Output Plug-In 2080-OF2 2080OF2

Description:

The Allen-Bradley 2080-OF2 is a Micro800 2-point analog output plug-in module designed to provide additional analog output capability for Micro820 and Micro850 controllers. It delivers precise voltage or current output signals for controlling variable speed drives, valves, and other analog-controlled devices within compact automation systems. Commonly installed in packaging machines, small process skids, conveyor systems, and OEM equipment, this plug-in module expands controller functionality without increasing panel footprint. Maintenance teams and system integrators use this module for system upgrades, analog output expansion, retrofit applications, and replacement of failed plug-in modules in Micro800-based control systems.

Applications:

The 2080-OF2 analog output plug-in is used to send 0–10V or 4–20 mA control signals to field devices such as VFDs, control valves, and signal conditioners. It is widely applied in small manufacturing systems, HVAC control panels, pump stations, and standalone machinery where compact design and reliable analog signal control are required.

Technical Specifications:

• Manufacturer Part Number (MPN): 2080-OF2
• Brand: Allen-Bradley
• Product Family: Micro800
• Product Type: Analog Output Plug-In Module
• Compatible Controllers: Micro820, Micro850
• Number of Outputs: 2 analog outputs
• Output Signal Types: Voltage and Current
• Voltage Range: 0–10V DC
• Current Range: 0–20 mA, 4–20 mA
• Resolution: 12-bit
• Mounting: Plug-in module (controller-mounted)
• Operating Temperature: 0 to 55°C (32 to 131°F)

Common Replacements:

• Allen-Bradley 2080-IF2
• Allen-Bradley 2080-OF4
• Allen-Bradley 1762-OF4
