Analog Devices DC590B QuikEval USB Serial Controller Demo Board

Analog Devices' DC590B QuikEval USB Serial Controller Demo Board is an isolated USB serial controller designed to work with Linear Technology QuikEval-compatible demo boards. It provides SPI and I2C ports to connect the target demo circuitry while maintaining galvanic isolation from the host PC, often eliminating the need for an external power supply. The DC590B pairs with the QuikEval software package, which detects the connected demo board and loads the appropriate control screen to drive measurements and data acquisition. Used within the QuikEval ecosystem, the DC590B enables evaluation of a wide range of Analog Devices Inc. products, including ADCs, DACs, SMBus power-control devices, and many others, through the QuikEval interface and software. The package includes essential documentation such as a demo board schematic, user guide, and an evaluation design file to support rapid hardware setup and testing.
