Autoquip SERIES 35 Hand Control And Transformer 3ph 460v-ac Hand Control And Transformer

Autoquip Series 35 Hand Control and Transformer is a 460V three‑phase hand‑control power module designed for Autoquip Series 35 lift and tilt equipment. It accepts 460 VAC, 3‑phase input at 60 Hz and provides 24 VAC control power through a 45 VA transformer to feed the Series 35 controller circuitry, including the motor starter/contactor and related control devices. The unit is intended to be integrated inside a NEMA enclosure with pre‑wired connections to the power unit and external fusing as noted in the electrical schematics; secondary fusing is described in the Series 35 documentation. This hand control and transformer assembly supports pendant pushbuttons or foot control arrangements used to operate lift, tilt, or turntable functions, and is compatible with other Series 35 components such as powered turntables and scissor lift tables that run on 460V/3PH power with 24V control signals. By delivering the high‑voltage input to a dedicated transformer, it isolates and supplies the low‑voltage control circuitry, enabling reliable operation of safety interlocks, limit switches, and pilot controls in demanding industrial environments.
