Axiomtek ICO320-83C-N4200-4LAN-4COM-TPM-WT-DC-RAP-12-24VDC Processor Module

Axiomtek ICO320-83C-N4200-4LAN-4COM-TPM-WT-DC-RAP-12-24VDC is a rugged, fanless DIN-rail edge computer built around Intel processors, available with either Celeron N3350 or Pentium N4200 performance for industrial applications. It provides four Gigabit Ethernet ports for reliable network connectivity and four serial (COM) interfaces to support legacy devices, along with an onboard TPM 2.0 module for hardware-based security. The system accepts a wide 12–24 VDC input and is designed for wide-temperature operation in harsh environments (WT variant specified for -40°C to +70°C). Memory is one DDR3L-1866 SO-DIMM slot, supporting up to 8 GB, enabling responsive multitasking and local data processing. Storage flexibility is achieved with support for a 2.5" SATA drive, suitable for OS, logging, and local data storage. Video output is available via a VGA port, and two USB 3.0 ports expand peripheral options. Management and integration are aided by AXView software for remote monitoring, with Windows 10 IoT and Linux support packages available by request. This configuration emphasizes expandability and reliability for industrial edge tasks such as IP video surveillance, factory automation, and remote IoT gateways, delivering a compact, DIN-rail-ready platform that combines secure compute, multiple communication interfaces, and robust thermal performance in a single, purpose-built module.
