The Baldor Electric M3704T is a 3 HP, three‑phase induction motor with a totally enclosed fan‑cooled (TEFC) enclosure designed for general‑purpose industrial duty. It operates at 60 Hz with a 213T frame and yields 1165 RPM when fed from 208–230 V or 460 V in a dual‑voltage, three‑phase system. The nameplate lists a service factor of 1.15, insulation class F, ambient temperature rating of 40°C, and full‑load current around 9.9 A at 208–230 V or about 4.6 A at 460 V (NP1256L, design B, code K). This motor is intended for continuous‑duty use in general‑purpose mechanical systems.
