Cisco AIR-ANT3338 AIRONET 2.4GHz 21dBi SOLID WLAN PARABOLIC DISH ANTENNA AIRANT3338

DESCRIPTION

The Cisco AIR-ANT3338 is a directional patch antenna designed for use with Cisco Aironet wireless access points operating in the 2.4 GHz frequency band. With a gain of 6 dBi, this antenna is ideal for extending coverage in a specific direction—such as long hallways, open office areas, or warehouse aisles—while minimizing interference in undesired directions. It includes an integrated mounting bracket and RP-TNC connector for quick deployment.

TECHNICAL SPECIFICATIONS

Model: AIR-ANT3338
Frequency Range: 2400 – 2483 MHz (2.4 GHz band)
Antenna Type: Directional patch
Gain: 6 dBi
VSWR: Less than 2:1
Polarization: Linear, vertical
Beamwidth:
– Horizontal: ~75°
– Vertical: ~60°
Connector Type: RP-TNC Plug
Impedance: 50 Ohms
Dimensions (H x W x D): ~12.7 x 12.7 x 1.9 cm (5 x 5 x 0.75 in)
Mounting: Wall or mast mount (bracket included)
Environment: Indoor/outdoor capable
Operating Temperature: -20°C to +60°C
