Cisco AIR-CT3504-K9 3504 IEEE 802.11ac Wireless LAN Controller AIRCT3504K9

Description:

The Cisco AIR-CT3504-K9 is a compact and high-performance wireless LAN controller designed for small to medium-sized enterprises and branch deployments. Supporting up to 150 access points and 3,000 clients, it enables reliable and secure wireless connectivity with advanced features like CleanAir, TrustSec, and Application Visibility and Control (AVC). With built-in support for Cisco DNA and SD-Access, this 1RU controller delivers centralized management, flexible deployment options, and high throughput in a space-saving form factor.

TECHNICAL SPECIFICATIONS:

Manufacturer: Cisco Systems
Series: Cisco 3504 Wireless Controller
Model Number: AIR-CT3504-K9
Access Point Support: Up to 150 APs
Client Support: Up to 3,000 wireless clients
Data Throughput: Up to 4 Gbps
Form Factor: 1 RU, rack-mountable
Processor: 8-core 1.5 GHz
Memory: 8 GB DDR4
Storage: 32 GB eMMC flash
Network Interfaces:
1x 5-Gigabit Multigigabit Ethernet
4x 1-Gigabit Ethernet (2 PoE capable)
2x 1-Gigabit service ports (redundancy and out-of-band management)
Console Ports: 1x RJ-45, 1x mini-USB
USB Port: 1x USB 3.0
Wireless Standards: 802.11a/b/g/n/ac (Wave 1 and Wave 2)
Ethernet Standards: 10/100/1000BASE-T, 802.1Q VLAN tagging, 802.3az, 802.1AX (LACP)
Power Supply: External 115W (dual-output: 54V/12V), ~80W max power consumption
Operating Temperature: 0 to 40°C (32 to 104°F)
Storage Temperature: –20 to 70°C (–4 to 158°F)
Humidity: 5% to 95% non-condensing
Security Features: Cisco CleanAir, TrustSec, BYOD support, Safe Client Profiling, AVC/NBAR2, DPI
Management & Licensing: Smart Licensing, DNA support, Right-to-Use licensing model
Dimensions (HxWxD): Approx. 1.72 x 8.0 x 10.0 in (43.6 x 203 x 254 mm)
