Cisco Meraki MX64W-HW Cloud-Managed Router Security Appliance MX64WHW

Description:

The Cisco Meraki MX64W-HW Cloud-Managed Router Security Appliance (MX64WHW) is used in enterprise network security systems to provide integrated firewall protection, routing, and wireless connectivity through centralized cloud management. This compact security appliance combines advanced firewall features, VPN connectivity, traffic shaping, and built-in wireless networking to support secure internet access and site-to-site connectivity for branch offices and remote locations. Managed through the Cisco Meraki cloud dashboard, the device allows administrators to monitor network performance, configure security policies, and manage multiple network sites from a centralized platform. Its integrated design simplifies deployment and maintenance, making it suitable for organizations requiring secure and scalable network connectivity with minimal on-site management.

Applications:

The Cisco Meraki MX64W-HW security appliance is commonly deployed in small to medium business networks, branch offices, retail stores, and distributed enterprise locations where secure internet access and wireless connectivity are required. It is widely used to protect local networks with firewall and VPN security while enabling centralized cloud-based network monitoring and configuration. The appliance supports secure connectivity for office workstations, point-of-sale systems, wireless devices, and remote users while maintaining reliable network performance across distributed environments.

Technical Specifications:

• Manufacturer Part Number (MPN): MX64W-HW
• Alternate Part Number: MX64WHW
• Brand: Cisco Meraki
• Product Type: Cloud-Managed Router and Security Appliance
• Firewall Throughput: Up to 250 Mbps
• VPN Throughput: Up to 100 Mbps
• Wireless Standard: 802.11ac integrated wireless access point
• Ethernet Ports: 4 x Gigabit Ethernet LAN ports
• WAN Interfaces: 1 x Gigabit Ethernet WAN port
• Security Features: Stateful firewall, VPN support, traffic shaping, content filtering
• Management Platform: Cisco Meraki Cloud Dashboard
• Mounting Type: Desktop or wall mount
• Application Environment: Branch offices and small enterprise networks

Common Replacements:

• Cisco Meraki MX67W-HW Cloud-Managed Security Appliance
• Cisco Meraki MX68W-HW Cloud-Managed Security Appliance
• Cisco Meraki MX75-HW Cloud-Managed Security Appliance
