Cisco SFP-10G-ER-S 10GBASE-ER SFP Transceiver SFP10GERS

Description:

The Cisco SFP-10G-ER-S is a 10GBASE-ER SFP+ transceiver module designed for long-range 10 Gigabit Ethernet connectivity over single-mode fiber. Operating at a wavelength of 1550 nm, it supports transmission distances of up to 40 kilometers. This S-Class transceiver is hot-swappable and provides a cost-effective solution for enterprise and service provider applications where extended reach is required. It is ideal for data center interconnects, metro access, and backbone network links.

Technical Specifications:

Manufacturer: Cisco Systems
Model Number: SFP-10G-ER-S
Transceiver Type: SFP+
Standard: 10GBASE-ER
Fiber Type: Single-mode fiber (SMF)
Wavelength: 1550 nm
Data Rate: 10 Gbps
Connector Type: Duplex LC
Maximum Distance: Up to 40 km (24.8 miles)
Compatibility: Cisco switches and routers with SFP+ ports
Hot-Swappable: Yes
Power Consumption: Approximately 1.5W
Digital Diagnostics (DOM): Yes
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Receiver Sensitivity: –15.8 dBm
Transmitter Power: –4.7 to +4.0 dBm
Dimensions: 13.4 mm x 8.5 mm x 56.5 mm
Weight: Approx. 0.018 kg (0.63 oz)
