CQM1-TC101 CQM1TC101 Programmable Controller

Description:

The Omron CQM1-TC101 temperature control unit is used in CQM1-series PLC systems for precise temperature regulation and monitoring in industrial automation processes. Commonly installed in packaging machines, plastic molding equipment, heating systems, and process control lines requiring accurate thermal management. Maintenance teams and system integrators use this part for replacement, retrofit, and maintaining stable temperature control in PLC-based systems.

Applications:

The Omron CQM1-TC101 temperature control unit is used in industrial environments where precise temperature monitoring and control are critical. It is applied in injection molding machines, food processing equipment, packaging systems, and industrial ovens to regulate heating elements and maintain consistent process temperatures, ensuring product quality and operational efficiency.

Technical Specifications:

• Manufacturer: Omron
• Part Number: CQM1-TC101
• Product Type: Temperature Control Unit
• Series: Omron CQM1 Series
• Number of Control Loops: 1 loop
• Input Type: Thermocouple / Platinum resistance thermometer (model dependent)
• Control Method: PID control
• Output Type: Transistor / control output (model dependent)
• Temperature Range: Wide range depending on sensor type
• Accuracy: High precision temperature control
• Connection Type: Screw terminal
• Mounting Type: Rack mount (CQM1 PLC rack)
• Functions: Auto-tuning, alarm outputs, heater burnout detection
• Operating Temperature: 0°C to +55°C

Common Replacements:

• Omron CQM1-TC102 Temperature Control Unit
• Omron CJ1W-TC001 Temperature Control Unit
• Omron NX-TC2405 Temperature Control Unit
