Delta PLC DVP20SX211T (8DI, 6DO NPN Transistor, 4AI, 2AO)

Description:

The Delta DVP20SX211T programmable logic controller is used in industrial automation systems to provide integrated digital and analog control for machine and process applications. Commonly installed in packaging machines, conveyors, temperature control systems, and small to mid-scale production lines where compact PLC control is required. Maintenance teams and system integrators use this PLC for system control, automation upgrades, and replacement of existing PLC units.

Applications:

The Delta DVP20SX211T PLC is commonly deployed in industrial automation environments where both digital and analog control are required in a compact controller. It is used in manufacturing lines, HVAC systems, water treatment plants, packaging equipment, and process control systems to manage sensors, actuators, and motors while enabling precise PID control, real-time monitoring, and communication with HMIs and SCADA systems.

Technical Specifications:

• Manufacturer: Delta Electronics
• Manufacturer Part Number: DVP20SX211T
• Product Series: DVP-SX2 Series
• Product Type: Programmable Logic Controller (PLC)
• Power Supply: 24 VDC
• I/O Configuration: 20 points (8DI, 6DO, 4AI, 2AO)
• Output Type: Transistor (NPN)
• Program Capacity: 16k steps
• Execution Speed: 0.35 µs per instruction
• Communication Ports: USB, RS-232, RS-485
• Protocol Support: Modbus ASCII / RTU
• High-Speed Pulse Output: Up to 100 kHz
• Analog Inputs: 4 channels (voltage/current)
• Analog Outputs: 2 channels (voltage/current)
• Mounting Type: DIN rail / panel mount
• Operating Temperature: 0°C to 55°C

Common Replacements:

• Delta DVP20SX211R PLC (Relay Output Version)
• Delta DVP20SX311T PLC (Next Generation Model)
• Delta DVP12SA211T PLC
