Fanuc A06B-0227-B705 Servo Motor 3ph 1.6kw 3000rpm 8nm 200-240v-ac A06B0227B705

Description:

The FANUC A06B-0227-B705 AC Servo Motor is used in industrial motion control systems to provide precise positioning, speed, and torque control for automated machinery. Commonly installed in CNC machines, robotics, and automated production equipment requiring stable and high-performance servo operation. Maintenance teams, OEMs, and system integrators use this part for replacement, retrofit, and upgrading of servo-driven systems.

Applications:

The FANUC A06B-0227-B705 servo motor is widely used in industrial automation environments where accurate motion control and reliability are essential. It is commonly applied in CNC machining centers, lathes, robotic arms, conveyor automation, and precision manufacturing systems where smooth and consistent motion is required.

Technical Specifications:

• Manufacturer Part Number (MPN): A06B-0227-B705
• Product Type: AC Servo Motor
• Series: FANUC αi Series
• Rated Output Power: 1.6 kW
• Rated Voltage: 200–240 VAC, 3-phase
• Rated Speed: 3000 RPM
• Rated Torque: 8 Nm
• Phase: 3-phase
• Encoder Type: High-resolution encoder
• Shaft Type: Straight shaft (keyed)
• Cooling Method: Self-cooled
• Mounting: Flange mount

Common Replacements:

• FANUC A06B-0227-B100
• FANUC A06B-0227-B605
• FANUC A06B-0227-B707
