Festo DSNU-16-60-P-A ISO 6432 Pneumatic Cylinder

Description:

The Festo DSNU-16-60-P-A Pneumatic Cylinder 1908263 is used in ISO 6432 standard round-body, double-acting pneumatic cylinder designed to provide precise and reliable linear motion in industrial automation systems. Commonly installed in packaging machinery, assembly equipment, conveyor systems, and material handling equipment where compact size and repeatable pneumatic actuation are required. Maintenance technicians, automation engineers, and system integrators use this cylinder for equipment repairs, machine upgrades, replacement of worn actuators, and OEM automation projects. Its stainless steel construction provides long service life and corrosion resistance.

Applications:

The Festo DSNU-16-60-P-A Pneumatic Cylinder is commonly used in packaging machinery, conveyor systems, robotic workstations, pick-and-place equipment, assembly machines, material handling systems, and factory automation applications where dependable linear motion and compact pneumatic actuation are critical.

Technical Specifications:

• Manufacturer: Festo
• Model / Part Number: DSNU-16-60-P-A
• Order Number: 1908263
• Product Type: Round Pneumatic Cylinder
• Series: DSNU
• Bore Size: 16 mm
• Stroke Length: 60 mm
• Cylinder Type: Double-Acting
• Standard: ISO 6432 / CETOP RP52P
• Cushioning: Elastic Cushioning Rings (P)
• Operating Pressure: 1 to 10 bar (14.5 to 145 PSI)
• Pneumatic Connection: M5
• Piston Rod Thread: M6 Male
• Position Detection: Compatible with Proximity Sensors
• Barrel Material: Stainless Steel
• Piston Rod Material: High-Alloy Stainless Steel
• Operating Medium: Filtered Compressed Air
• Ambient Temperature: -20°C to +80°C
• Application Environment: Industrial automation and pneumatic systems

Common Replacements:

• Festo DSNU-16 Series Pneumatic Cylinder
• Festo DSNUP-16 Series Pneumatic Cylinder
• SMC C85 Series Air Cylinder
