HPE Aruba J9776A 24G Switch 24 Port Ethernet Networking Switch P/N: J9776A

Description:

The HPE J9776A is a 48-port Gigabit Layer 2 managed switch from the HPE 2530 Series. It provides full Power over Ethernet Plus (PoE+) support on all ports and includes four dedicated SFP uplink ports for fiber connectivity. Designed for cost-effective, reliable performance in enterprise edge, branch office, and SMB environments, the switch offers robust security, traffic management, and energy-saving features. It is easy to deploy and manage, making it ideal for converged network environments supporting voice, video, and data.

TECHNICAL SPECIFICATIONS:

Model: J9776A
Series: HPE 2530
Ports: 48 x 10/100/1000Base-T (PoE+), 4 x SFP uplinks
PoE Standard: IEEE 802.3af/at (PoE+)
PoE Budget: 382W
Layer: 2
Switching Capacity: 104 Gbps
Forwarding Rate: 77.4 Mpps
MAC Address Table: 16,000 entries
Management: Web GUI, CLI, SNMP, RMON
Security Features: ACLs, IEEE 802.1X, RADIUS
Power Supply: Internal, fixed
Mounting: Rack-mountable (1U)
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Dimensions: 44.25 cm x 24.6 cm x 4.39 cm (17.42 in x 9.69 in x 1.73 in)
Weight: Approx. 4.4 kg (9.7 lbs)
Certifications: CE, UL, FCC, RoHS, ENERGY STAR
