IDEM Safety KM-203011 Safety Interlock Switch

Description:

The IDEM KM-203011 Safety Interlock Switch is a tongue-operated safety switch designed to monitor the position of sliding, hinged, or lift-off machine guards in industrial safety systems. It features a robust die-cast aluminum housing with a 90° adjustable head and 2 normally closed (NC) safety contacts plus 2 normally open (NO) auxiliary contacts. The switch provides positive-opening safety contacts and anti-tamper protection, making it suitable for medium- to heavy-duty machine guarding applications.

Applications:

The IDEM KM-203011 Safety Interlock Switch is used on machine guards for CNC equipment, packaging machinery, robotic cells, conveyors, presses, and automated production equipment. It ensures hazardous machinery cannot operate unless the guard is securely closed and immediately interrupts the safety circuit when the actuator key is withdrawn.

Technical Specifications:

• Manufacturer: IDEM Safety Switches
• Manufacturer Part Number (MPN): KM-203011
• Product Type: Tongue-operated safety interlock switch
• Function: Machine guard position monitoring and safety interlocking
• Contact Configuration: 2 NC safety contacts, 2 NO auxiliary contacts
• Contact Action: Slow action, positive opening safety contacts
• Actuator Type: Tongue (key) operated
• Head Adjustment: 90° adjustable with 8 actuator entry positions
• Housing Material: Die-cast aluminum
• Head Material: Die-cast aluminum
• Conduit Entry: One 1/2 in. NPT female opening
• Mounting Profile: 30 mm
• Protection Features: Positive-opening contacts, anti-tamper mechanism
• Compatible Equipment: CNC machines, conveyors, packaging equipment, robotic systems, presses, and industrial automation machinery
• Operating Environment: Industrial machine safety applications
• Application: Machine guard interlocking and personnel protection
• Designed For: Medium- to heavy-duty moving guard safety systems.

Common Replacements:

• IDEM KM-203011 Tongue Safety Interlock Switch
• IDEM KM-203011-SS (stainless steel head version; verify environmental requirements)
• Equivalent tongue-operated safety interlock switch with 2 NC + 2 NO contacts, 30 mm mounting profile, and 90° adjustable head
