HPE Aruba J9727A J9727-61001 2920-24G-PoE+ Ethernet Switch HPE F/S

Description:

The HPE Aruba J9727A is a 2920-48G-POE+ Switch, part of the Aruba 2920 Series. This managed Layer 3 switch provides 48 Gigabit Ethernet ports with PoE+ support and 4 dual-personality ports, allowing for either RJ-45 or SFP connectivity. Designed for scalable enterprise edge and SMB deployments, the J9727A features advanced security, QoS, and energy-efficient technologies. With support for stacking, dynamic segmentation, and flexible management options, this switch offers robust performance in converged wired and wireless networks.

TECHNICAL SPECIFICATIONS:

Model: J9727A
Series: Aruba 2920
Form Factor: 1U Rackmount
Ports:
48 x 10/100/1000Base-T PoE+ ports
4 x Dual-personality (RJ-45 or SFP) ports
PoE Power Budget: 370W
Stacking Capability: Up to 4 switches via optional stacking module
Switching Capacity: 104 Gbps
Throughput: Up to 77.4 Mpps
Layer Support: Layer 2 and Layer 3 routing
MAC Address Table: 16,000 entries
Routing: Static and RIP, Access OSPF
Security Features:
802.1X authentication
MAC authentication
VLANs
Access Control Lists (ACLs)
Management:
 Web GUI
CLI
SNMP
Aruba AirWave
Centralized management via Aruba Central
Power Supply: Internal (auto-ranging 100–240V AC)
Redundancy: Optional redundant power supply
Cooling: Variable-speed fan
Dimensions: 44.25 cm x 32.26 cm x 4.39 cm (17.42 in x 12.7 in x 1.73 in)
Weight: Approx. 4.6 kg (10.14 lbs)
