HPE JG536A JG536-61001 JG536-61101 Office Connect 1910-8 SWITCH HPE F/S

Description:

The HPE JG536A is a 5130-24G-PoE+-4SFP+ EI Layer 3 Ethernet switch, engineered for enterprise access and aggregation deployments. This switch features 24 Gigabit PoE+ ports and 4 high-speed SFP+ uplinks, delivering robust performance, intelligent management, and advanced Layer 3 functionality. With support for PoE+, IRF stacking, and strong security features, the JG536A is ideal for high-density campus environments and converged networks requiring efficient data and power delivery.

Technical Specifications:
Manufacturer: Hewlett Packard Enterprise (HPE)
Model: JG536A (also known as JG536-61001, JG536-61101)
Series: HPE 5130 EI Series
Switch Type: Layer 3 Managed Ethernet Switch
Ports: 24 x 10/100/1000BASE-T (PoE+)
Uplink Ports: 4 x SFP+ (10GbE)
PoE Support: IEEE 802.3af/at (PoE+), up to 30W per port
PoE Budget: Up to 370W (with external power supply)
Switching Capacity: 128 Gbps
Forwarding Rate: 95 Mpps
MAC Address Table Size: 32K entries
Routing Protocols: Static Routing, RIP, OSPF
Stacking: IRF (supports up to 9 units)
Management: Web GUI, CLI, SNMP v1/v2/v3, RMON, SSH, HTTPS
Security Features: 802.1X, DHCP snooping, port security, ACLs
Power Supply: Internal, hot-swappable (model dependent)
Mounting: Rack-mountable (1U)
Fan: Variable-speed intelligent fan
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Dimensions: 44.2 x 36 x 4.4 cm (17.4 x 14.2 x 1.73 in)
Weight: Approx. 6.3 kg (13.9 lb)
