HPE JG538A JG538A#ABA 1910-24 SWITCH HPE Factory F/S

Description:

The HPE JG538A (HPE Part Number JG538A#ABA) is a smart-managed 24-port Fast Ethernet switch from the OfficeConnect 1910 Series, designed for small to medium-sized business networks. It features 24 10/100 Mbps RJ-45 ports and 2 combo Gigabit SFP uplink ports, offering flexible and cost-effective connectivity. With support for Layer 2 switching and basic Layer 3 static routing, the JG538A enables efficient traffic control and network segmentation. It provides intuitive web-based management, advanced security features, and energy-efficient operation—making it an ideal solution for growing business environments.

Technical Specifications:

Manufacturer: Hewlett Packard Enterprise (HPE)
Model Number: JG538A
HPE Part Number: JG538A#ABA
Series: OfficeConnect 1910
Switch Type: Smart-managed Layer 2+
Port Count: 24 x 10/100 RJ-45 + 2 x combo Gigabit SFP
Switching Capacity: 8.8 Gbps
Forwarding Rate: 6.6 Mpps
MAC Address Table: 8,192 entries
Static Routing: Up to 32 routes
VLAN Support: Up to 256 VLANs
QoS: Layer 2 prioritization, rate limiting
Security Features: Access control lists (ACLs), 802.1X, SSL
Management: Web GUI, CLI (limited), SNMP v1/v2c/v3
Jumbo Frame Support: Yes (up to 9216 bytes)
Power Supply: Internal 100–240V AC
Power Consumption: Approx. 12W
Form Factor: Rack-mountable (1U)
Dimensions: 17.4 in x 6.7 in x 1.7 in (44.3 cm x 17.1 cm x 4.4 cm)
Weight: 2.2 kg (4.85 lb)
