HPE JH390A FlexFabric 5940 48SFP+ 6QSFP28 Managed Switch HPE F/S

Description:

The HPE Aruba JH390A is a 2540 Series 48G 4SFP+ Switch, designed for enterprise edge, SMB, and branch office deployments. It features 48 Gigabit Ethernet ports and 4 SFP+ uplink ports for 10GbE connectivity, delivering high-performance access layer switching. With advanced Layer 2 features, optional Layer 3 routing, and robust security and management capabilities, this switch supports both cloud-based and on-premises Aruba Central management. It offers flexible deployment, enhanced traffic control, and energy-efficient operation with support for IEEE 802.3az (Energy Efficient Ethernet).

TECHNICAL SPECIFICATIONS:

Model: JH390A
Series: HPE Aruba 2540
Ports: 48 x 10/100/1000BASE-T, 4 x 1/10GbE SFP+
Switching Capacity: 176 Gbps
Throughput: 130.9 Mpps
Latency: <3.8 µs (64-byte packets)
MAC Address Table: 16,000 entries
Packet Buffer Size: 1.5 MB
VLANs Supported: Up to 512
Layer Support: Layer 2 with static Layer 3 routing
Power Supply: Internal, fixed
Management: Web GUI, CLI, SNMP, Aruba AirWave, Aruba Central
Security: ACLs, port security, DHCP snooping, RADIUS, TACACS+
Mounting: Rack-mountable (1U)
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Dimensions: 44.25 cm x 32.29 cm x 4.39 cm (17.42 in x 12.71 in x 1.73 in)
Weight: Approx. 4.1 kg (9.04 lbs)
