HPE Aruba JL368A 8400 Management Module JL368A

Description:

The HPE Aruba JL368A is an Aruba 2930F 48G PoE+ 4SFP+ switch designed for enterprise edge, SMBs, and branch office networks. With Layer 3 capabilities and support for cloud-based management via Aruba Central, this switch offers 48 Gigabit PoE+ ports and four 10GbE SFP+ uplinks. It enables flexible, secure, and cost-effective deployments with advanced features like static routing, ACLs, and Zero Touch Provisioning, making it ideal for organizations needing scalable performance and PoE support.

Technical Specifications:

Manufacturer: Hewlett Packard Enterprise (Aruba Networks)
Model: JL368A
Series: Aruba 2930F Series
Switch Type: Layer 3 Managed Switch
Ports: 48 x 10/100/1000BASE-T (PoE+)
Uplink Ports: 4 x SFP+ (10GbE)
PoE Support: IEEE 802.3af/at (PoE/PoE+)
PoE Budget: Up to 370W
Switching Capacity: 176 Gbps
Forwarding Rate: 131 Mpps
Routing: Static and RIP routing
Stacking: Virtual Stacking Framework (VSF)
Management: Aruba Central, CLI, Web GUI, SNMP, REST API
Security: ACLs, RADIUS, TACACS+, 802.1X, DHCP Snooping
Mounting: Rack-mountable (1U)
Power Supply: Internal, fixed
Fan: Variable speed
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Dimensions: 44 x 30.5 x 4.39 cm (17.3 x 12 x 1.73 in)
Weight: Approx. 4.6 kg (10.1 lb)
