KOYO TRD-NA360NW5M Rotary Encoder TRDNA360NW5M

Description:

TRDNA360NW5M METRIC ENCODERS SERIES TRD-NA Product Description The KOYO TRD-NA360NW5M is a rotary encoder designed for precise and reliable measurement of rotational position and speed in industrial applications. This incremental encoder offers a resolution of 360 pulses per revolution (PPR), providing accurate feedback for various motion control and automation systems. The TRD-NA360NW5M features a robust design with a durable construction, ensuring reliable performance even in challenging environments. Its compact size and flexible mounting options make it suitable for integration into a wide range of industrial machinery and equipment.

Technical Specifications:

• Model Number: TRD-NA360NW5M
• Type: Incremental Rotary Encoder
• Resolution: 360 PPR (pulses per revolution)
• Output Type: NPN open collector output
• Shaft Diameter: 6 mm
• Supply Voltage: 5-12V DC
• Max Rotational Speed: Typically up to 5000 RPM
• Output Phases: A, B, Z (quadrature output with index pulse)
• Operating Temperature: -10°C to +70°C (14°F to 158°F)
• Protection Rating: IP50 (dust-protected)
• Housing Material: Metal or high-durability plastic
• Mounting: Flange or clamp mounting options
