Mitsubishi 7126RT-24W-B30-S02 Cooling Fan For Spindle Motor 7126RT24WB30S02

Description:

The 7126RT24WB30S02 is a high-quality, compact relay from Omron, designed to provide reliable switching and control in various industrial and commercial applications. This relay features a robust build with a 24V DC coil voltage, making it suitable for controlling circuits in automation and control systems. With a switching capacity of 30A, it is capable of handling significant load currents, ensuring dependable operation in demanding environments. The 7126RT24WB30S02 is engineered for long-lasting performance and durability, making it an excellent choice for switching heavy loads with precision.

Technical Specifications:

• Model: 7126RT24WB30S02
• Type: Power relay
• Coil Voltage: 24V DC
• Contact Configuration: 1 Form C (SPDT: Single Pole Double Throw)
• Contact Rating: 30A at 250V AC
• Switching Voltage: 250V AC or 30V DC
• Switching Current: 30A (maximum)
• Contact Resistance: 100 mΩ (initial value)
• Operate Time: 20 ms (typical)
• Release Time: 10 ms (typical)
• Insulation Resistance: 100 MΩ (at 500V DC)
• Dielectric Strength: 4000V AC (coil to contact)
• Operating Temperature: -40°C to 70°C
• Dimensions (W x H x D): Approximately 29.5 mm x 24.5 mm x 22 mm
• Weight: Approximately 30 grams
