Mitsubishi A1SY40P Positioning Module A1SY40P

Description:

The Mitsubishi A1SY40P Positioning Module is used in Mitsubishi MELSEC-A series PLC systems for digital output control of external devices in automation systems. Commonly installed in factory automation panels, machine control systems, conveyor equipment, and industrial process lines requiring transistor output interface. Maintenance teams, OEMs, and system integrators use this module for replacement, I/O expansion, or control system retrofit to maintain reliable PLC output control.

Applications:

The Mitsubishi A1SY40P is used in MELSEC-A PLC racks for controlling solenoids, relays, indicator lamps, small actuators, conveyor controls, packaging machinery, assembly equipment, and factory automation systems requiring 16-point DC transistor output control.

Technical Specifications:

• Brand: Mitsubishi
• Part Number: A1SY40P
• Product Type: Digital Output Module
• Series: MELSEC-A / AnS Series
• Output Points: 16 outputs
• Output Type: Transistor (sink type)
• Load Voltage: 12/24 V DC
• Load Current: 0.1 A per point
• Maximum Current: 0.8 A per common
• Isolation: Photocoupler isolation
• Response Time: Approx. 1 ms
• Operating Voltage Range: 10.2–30 V DC
• Protection: Short-circuit protection
• Mounting: A series base unit rack mount
• Application: PLC digital output control

Common Replacements:

• Mitsubishi A1SY40
• Mitsubishi A1SY41
• Mitsubishi QY40P
