Mitsubishi FR-D720-2.2K ( FRD72022K ) 3 Phase 220V Frequency Inverter FRD72022K

DESCRIPTION
The Fuji Electric FRD72022K is a compact FRENIC-Mini variable frequency drive (VFD) designed for controlling three-phase motors in small machinery and general-purpose applications. With a 2.2 kW (3 HP) power rating and three-phase 200–240V AC input, this drive offers excellent performance in a compact form factor. It includes features such as PID control, torque vector control, and built-in braking transistor for enhanced motor operation.

TECHNICAL SPECIFICATIONS
Model: FRD72022K
Series: FRENIC-Mini
Power Rating: 2.2 kW (3 HP)
Input Voltage: 3-phase 200–240V AC, 50/60 Hz
Output Voltage: 3-phase 0–240V AC
Output Current: Approx. 10 A
Control Method:
– V/F control
– Slip compensation
– Dynamic torque vector control
Frequency Range: 0.1 to 400 Hz
Built-in Functions:
– PID control
– Built-in braking transistor
– Auto-restart and energy-saving modes
Digital Inputs: 5
Digital Outputs: 1
Analog Inputs: 2
Communication: Optional RS-485 Modbus RTU
Protection: Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling: Internal fan
Mounting: DIN rail or panel
Enclosure Rating: IP20
Dimensions: Approx. 130 x 110 x 135 mm (varies slightly by model)
