Mitsubishi FX1N-24MT-001 MELSEC PLC Extendibility I/ O Analog Control FX1N4MT001

Description:

The Mitsubishi FX1N-24MT-001 is a programmable logic controller (PLC) from the MELSEC-FX1N series designed for compact industrial automation control with transistor outputs. Commonly installed in control panels, small machinery, conveyor systems, and packaging equipment, it provides reliable logic processing with high-speed switching outputs and flexible expansion capability. Maintenance teams, system integrators, and OEMs use this PLC for system control, upgrades, and replacements in automation environments requiring fast response and dependable performance.

Applications:

This Mitsubishi PLC is used in industrial automation environments requiring compact control with fast transistor output switching. Typical applications include small manufacturing machines, conveyor systems, packaging equipment, positioning systems, and material handling systems where high-speed signal output, precise control, and reliable logic execution are essential for efficient operation.

Technical Specifications:

• Manufacturer Part Number (MPN): FX1N-24MT-001
• Product Type: Programmable Logic Controller (PLC)
• Series: MELSEC-FX1N
• Total I/O Points: 24 (14 inputs, 10 outputs)
• Input Type: Digital DC (24 V)
• Output Type: Transistor (high-speed switching)
• Power Supply: 100–240 VAC or 24 VDC (model variant dependent)
• Program Memory: ~2000–8000 steps
• High-Speed Counters: Up to 60 kHz
• Pulse Output: Up to 100 kHz (positioning capable)
• Communication Interface: RS-422 programming port
• Expansion Capability: Expandable up to ~128 I/O points
• Power Consumption: Approx. 30 W
• Mounting Type: DIN rail mount
• Operating Temperature: 0 °C to 55 °C
• Protection Class: IP10–IP20

Common Replacements:

• Mitsubishi FX3S-30MT/ES
• Mitsubishi FX3G-24MT/ES-A
• Siemens S7-1200 6ES7212-1BE40-0XB0
