Mitsubishi FX2N-16MT-001 TRANSISTOR UNIT PLC MODULE FX2N16MT001

Description:

The Mitsubishi FX2N-16MT-001 Transistor Unit PLC Module is used in industrial control systems to provide high-speed digital output control for automation processes. Commonly installed in packaging machines, conveyor systems, CNC equipment, and automated production lines requiring fast and reliable transistor outputs. Maintenance teams, OEMs, and system integrators use this part for system expansion, replacement, and retrofit of Mitsubishi FX series PLC systems.

Applications:

The Mitsubishi FX2N-16MT-001 module is widely used in industrial automation environments where precise and high-speed switching is required. It is commonly applied in assembly machines, material handling systems, printing machines, labeling equipment, and small to medium-scale automation systems where transistor outputs are needed for driving relays, solenoids, and actuators.

Technical Specifications:

• Manufacturer Part Number (MPN): FX2N-16MT-001
• Product Type: PLC Transistor Output Module
• Series: MELSEC-FX2N
• Total I/O Points: 16
• Output Type: Transistor (sink/source depending on configuration)
• Rated Output Voltage: 24 VDC
• Output Current: Approx. 0.5 A per point
• Response Time: High-speed switching (microsecond level)
• Isolation: Photocoupler isolation
• Power Supply: External 24 VDC
• Mounting: DIN rail or panel mount
• Operating Temperature: 0°C to 55°C

Common Replacements:

• Mitsubishi FX2N-16MT-ESS/UL
• Mitsubishi FX2N-16MR-ES/UL
• Mitsubishi FX3G-14MT-DSS
