Mitsubishi FX3G-14MT/ES-A Programmable Controller FX3G14MT/ESA

Description:

The FX3G-14MT/ES-A is a compact and versatile programmable logic controller (PLC) from Mitsubishi's FX3G series, designed to deliver reliable control for small to medium-sized automation applications. It features 14 digital I/O points, combining inputs and outputs in a single, space-efficient unit. This PLC offers a range of advanced features and built-in functionality to support a variety of industrial processes, making it a flexible and efficient solution for control and automation tasks.

Technical Specifications:

• Type: Programmable Logic Controller (PLC)
• Number of I/O Points: 14 (8 inputs, 6 outputs)
• Input Type: Digital, Sink/Source selectable
• Output Type: Transistor
• Input Voltage Range: 24V DC
• Output Voltage Range: 24V DC
• CPU Type: Built-in CPU
• Memory: 8K steps of user memory
• Communication Ports: None built-in; optional expansion modules available
• Power Supply: 24V DC
• Operating Temperature Range: 0°C to 55°C
• Mounting Type: DIN Rail
