Mitsubishi FX3U-128MT-ESS PLC controller FX3U128MT/ESS

Description:

The Mitsubishi A1SD75M1 Positioning Unit Module is used in PLC-based automation systems to control precise positioning and motion of servo and stepper motors. Commonly installed in Mitsubishi A Series PLC racks within CNC machines, assembly systems, and automated production equipment. Maintenance teams, OEMs, and system integrators use this part for motion control upgrades, system expansion, and replacement of positioning modules.

Applications:

The Mitsubishi A1SD75M1 module is widely used in industrial automation environments requiring accurate and repeatable motion control. It is applied in packaging machinery, material handling systems, pick-and-place units, and assembly lines, enabling synchronized axis control and precise positioning for improved production efficiency and accuracy.

Technical Specifications:

• Manufacturer Part Number (MPN): A1SD75M1
• Brand: Mitsubishi Electric
• Product Type: Positioning Unit Module
• Series: MELSEC A Series
• Control Axes: 1-axis positioning control
• Output Type: Pulse train output (for servo/stepper drives)
• Control Method: Positioning / point table control
• Compatible Systems: Mitsubishi A Series PLC
• Interface: High-speed pulse output
• Mounting Type: PLC rack-mounted module
• Programming: PLC-based motion control programming
• Application Environment: Industrial automation, motion control systems

Common Replacements:

• Mitsubishi A1SD75M2 Positioning Module
• Mitsubishi QD75M1 Positioning Module
• Mitsubishi FX3U-20SSC-H Positioning Module
