Mitsubishi FX3U-32MR/ES-A Programmable Logic Module Controller Unit FX3U32MR/ESA

Description:

FX3U32MRESA PROGRAMMABLE CONTROLLER FX3U SERIES 8 AMP 100-240 VAC INPUT 30 VDC/ 240 VAC OUTPUT 50/60 HZ 35 W 32 INPUT/OUTPUT W/O BOTTOM TERMINAL COVER DIN RAIL MOUNT 0 TO +50 DEGREES C The FX3U-32MR/ES-A is a compact and versatile programmable logic controller (PLC) designed for a wide range of industrial automation tasks. Featuring 32 input/output points with 16 discrete inputs and 16 relay outputs, this model provides a flexible and reliable solution for controlling and monitoring machinery and processes. The FX3U-32MR/ES-A includes an integrated power supply and supports expansion with additional I/O modules to accommodate more complex applications. Its high-speed processing capabilities, combined with a user-friendly programming environment, make it ideal for a variety of automation and control applications, from simple to advanced systems.

Technical Specifications:

• Model: FX3U-32MR/ES-A
• Type: Compact PLC with built-in I/O
• Digital Inputs: 16 points (24V DC, sink/source)
• Digital Outputs: 16 points (Relay, 250V AC 2A)
• Power Supply: 24V DC ±10%
• Current Consumption: 600 mA (typical)
• Processing Speed: 0.08 μs per instruction
• Program Capacity: 30,000 steps
• Memory: 16KB RAM, 64KB EEPROM
• Communication Ports: 1x RS-232, 1x RS-485 (optional)
• Expansion: Compatible with FX3U expansion modules
• Enclosure Rating: IP20
• Operating Temperature: 0°C to +55°C
• Dimensions: 90mm x 90mm x 80mm
• Weight: 500g
