Mitsubishi FX3U-4AD-PT-ADP PLC Module FX3U4ADPTADP

Description:

The Mitsubishi FX3U-4AD-PT-ADP Analog Temperature Input Module is a special adapter designed for MELSEC-F FX3U series PLCs. It connects directly to the PLC base unit and converts temperature signals from RTD sensors into digital values for processing. Maintenance teams, OEMs, and system integrators use this module for replacement, retrofit, and precise temperature monitoring in industrial automation systems.

Applications:

The Mitsubishi FX3U-4AD-PT-ADP module is used in industrial automation systems requiring accurate temperature measurement, including process control, heating systems, packaging machines, and environmental monitoring. It is ideal for applications that demand compact expansion, multi-channel temperature input, and reliable integration with FX3U PLC platforms.

Technical Specifications:

• Brand: Mitsubishi Electric
• Part Number: FX3U-4AD-PT-ADP
• Product Type: Temperature Analog Input Adapter
• Series: MELSEC-F FX3U
• Number of Inputs: 4 temperature channels
• Input Type: RTD (Pt100) temperature sensors
• Resolution: High-resolution A/D conversion
• Conversion Time: High-speed multi-channel conversion
• Power Supply: From PLC base unit (no external supply required)
• Mounting Type: Left-side special adapter for FX3U CPU
• Isolation: Photocoupler isolation between analog and PLC
• Operating Temperature: 0°C to 55°C
• Application: Temperature measurement and process monitoring
• Compact Width: approx. 17.6 mm slim adapter design

Common Replacements:

• Mitsubishi FX3U-4AD-TC-ADP
• Mitsubishi FX5-4AD-PT-ADP
• Mitsubishi FX3U-4AD-ADP
